16mm HD LED Signs and Electronic Displays

The Sign-Express 16mm HD LED Signs are one of our best sellers. With a recommended minimum viewing distance of only 25 ft., images and video look excellent and read ability is far superior to other models. At a distance of 40+ Ft., you will think you are looking at a television screen. Sign-Express offers the 10mm HD resolution LED sign at a very affordable price for any business or organization. Contact us by completing the easy web contact form to learn more about this state-of-art 16mm LED sign.

Manufactured in the USA

Sign-Express LED signs are designed in the USA, Manufactured in the USA, and include technical support stationed right here in the USA.

Advanced Control Systems

Sign-Express offers a robust embedded control system designed to operate in harsh climates. The high-performance Linux controller adds stability and built-in protection from unauthorized access. An optional upgraded PC based control system allows for expandability and lives video capability. The PC control system will also integrate with other third-party software solutions allowing you the flexibility you deserve.

LED Module Design

Utilizing a universal module design of 320mm or 12 1/2″ sizes, Sign-Express is able to fit any resolution into the perfect size for your signage solution. Our latch system means no screws to lose or discolor on the face of your sign and the triple seal gaskets protect against all water and dust giving it an IP68 rating, one of the highest in the market. The back of the module is con-formal coated for added protection against water and salt molecules that enter the ventilation system. Only top quality LED’s are used to ensure your signs brightness and color balance will last for years to come.

Con-formal Coated Power Supplies

Only the best of the best, MeanWell® power supplies, are used in the construction of the Sign-Express line of signs. Optimized for the highest power efficiency to save you money and added con-formal coating to protect against water and salt molecules in the air. The life of your power supply is increased and so is the life of your LED sign.

Climate Control Features

Thermostatically controlled fans activate only when the display reaches 85 degrees and move air to coll off the internal components. Unique front venting technology allows for fresh airflow from the front of the cabinet and exhausting hot air to the rear.  This ensures that only cool fresh air enters the cabinet, which reduces the internal temperature by an astounding 20%.  Waterproof connectors on the back of the sign protect the communication and electrical connections into the LED sign.

Aluminum Cabinet Construction

Lightweight and rustproof aluminum cabinets, built right here in our factory, are used to house the Sign-Express line of LED signs. Aluminum cabinets is proven to better resist heat, rust and make installation a breeze from reduced weight. Sign-Express includes a continuous aluminum mounting bracket, top, and bottom of the cabinet, for easy bolt-up installation.  Integrated steel saddle systems are an option if you are wanting to install the displays yourself.

Product Safety & Certification

All of our products are tested and built to ensure safe operation outdoors. All components including, terminal blocks, connectors, power supplies, high voltage wire, low voltage wire, etc are UL certified and are compliant with UL specifications.

OEM Warranty

All of our high definition products are backed by a (3) five-year parts with a factory labor warranty. Sign-Express offers an extended five (5) year factory labor warranty and an additional five (5) year On-Site labor warranty with a small co-pay per incident for an extra cost, this reduces your out of pocket in the future and gives you peace of mind for years to come. Let us take care of everything

Resolution / Pitch16mm
Color Capability281 Trillion Colors
Brightness>10,000 Nits
Pixel Composition1 Red / 1 Green / 1 Blue
Viewing Angle160 degree
Contrast Ratio1000:1
Refresh Rate2000 MHz
Graphic CapabilityText, Pictures, Video (jpg, bmp, gif, swf, wmv, avi, mp4)
Operating Temperature-40F to +140F
LED Life-span100,000 Hrs.
Auto Dimming Levels10-250 Levels
Service AccesFront Service. Removable Modules
CommunicationTCP/IP with RJ45 input, Optional Cellular, Optional wireless communication
Warranty3 Year Parts / Factory Labor, Optional 5  Year Parts / Factory Labor, Optional On-Site Service Warranty
