20mm Tri-Color LED Signs

///20mm Tri-Color LED Signs
20mm Tri-Color LED Signs 2017-06-28T11:17:33+00:00
20mm Tri-Color LED Signs

20mm Tri-Color LED Signs and Electronic Displays

The Sign-Express 20mm Tri-Color LED Sign model is cost effective outdoor LED sign solution that far surpasses a simple monochrome or single color grayscale LED sign.  Our Tri-Color LED signs can create red, Green and Amber colors or a combination of all three.  The signs can do 8192 shades of brightness allowing you to show images with shading for more clarity.  Contact us by completing the easy web contact form to learn more about this cost effective 20mm Tri-Color LED sign.

Manufactured in the USA

Sign-Express LED signs are designed in the USA, Manufactured in the USA and include technical support stationed right here in the USA.

Advanced Control Systems

Sign-Express offers a robust embedded control system designed to operate in harsh climates. The high performance Linux controller adds stability and built in protection from unauthorized access. An optional upgraded PC based control system allow for expand ability and live video capability. The PC control system will also integrate with other third party software solutions allowing you the flexibility you deserve.

LED Module Design

Our latch system means no screws to lose or discolor on the face of your sign and the triple seal gaskets protect against all water and dust giving it an IP65 rating, one of the highest in the market. The back of the module is con-formal coated for added protection against water and salt molecules that enter the ventilation system. Only top quality LED’s are used to ensure your signs brightness and color balance will last for years to come.

Con-formal Coated Power Supplies

Only the best of the best, MeanWell® power supplies, are used in the construction of the Sign-Express line of signs. Optimized for the highest power efficiency to save you money and added con-formal coating to protect against water and salt molecules in the air. The life of your power supply is increased adn so is the life of your LED sign.

Climate Control Features

Thermostatically controlled fans activate only when the display reaches 85 degrees and move air to coll off the internal components. Waterproof connectors on the back of the sign protect the communication and electrical connections into the LED sign.

Aluminum Cabinet Construction

Lightweight and rustproof aluminum cabinets, built right here in America, are used to house the Sign-Express line of LED signs. Aluminum cabinets is proven to better resist heat, rust and make installation a breeze from reduced weight. Sign-Express includes a continuous aluminum mounting bracket, top and bottom of the cabinet, for easy bolt up installation.

Line-X® Cabinet Coating

A patented Line-X® coating is applied to the entire aluminum cabinet to both seal and protect against scratches and damage.

Product Safety & Certification

All of our products are tested and certified to ensure safe operation outdoors. MET Lab® Certified – compliant with UL specifications (UL48, UL8750 an UL1433)

OEM Warranty

All of our high definition products are backed by a (5) five year parts with factory labor warranty. Sign-Express offers an extended On-Site labor warranty with a small co-pay per incident, this reduces your out of pocket in the future and gives you peace of mind for years to come. Let us take care of everything

Specification Description
Resolution / Pitch 20mm
Color Capability 8192 Shades
Brightness >8,000 Nits
Pixel Composition 1 Red / 1 Green
Viewing Angle 160 degree
Contrast Ratio 1000:1
Refresh Rate 2000 MHz
Graphic Capability Text, Pictures, Video (jpg, bmp, gif, swf, wmv, avi, mp4)
Operating Temperature -40F to +140F
LED Life-span 100,000 Hrs.
Auto Dimming Levels 250 Levels
Service Acces Front Service. Hinged cabinets with Removable Modules
Communication TCP/IP with RJ45 input, Optional wireless communication
Certification MET Lab / UL48, UL8750, UL1433
Warranty 5 Year Parts / Factory Labor, Optional On-Site Service Warranty
20mm
